Sanyou has its own factory and can offer high quality shoe sewing machines that are designed specifically for sewing athletic shoe uppers. They are optimized for the unique characteristics of soft, elastic fabrics like mesh, which are both soft and highly elastic.
Our system can be set to apply "counter-pressure" to the presser foot at the start and end of the stitch. Our system can be set to have the presser foot perform "counter pressure" at the start and end of stitching, which allows the material to instantly increase its density while being compressed, eliminating the effect of elasticity on the thread loop.
The sewing range of this machine is 300MM*200MM. For shoe upper sewing, this sewing range can fully meet the needs of most shoe sizes and is very practical. Of course, we also offer other sizes, such as the compact 150*100mm or the larger 600*400mm, to meet all your custom sewing needs.
The Shoe Sewing Machines comes standard with a quick-change die fixture, allowing you to alternate between two die sets: one automatically sewing in the machine while a worker simultaneously sets the material outside. Our sewing machine system supports template management using barcodes, QR codes, or RFID recognition! The worker only needs to scan the template with the recognition device, and the machine will automatically recognize the pattern and start sewing. The machines can be centrally managed via Wi-Fi, making it much easier to monitor machine production.
| Standard Specifications | |||
| Model | 3020 | 3525 | |
| Sewing Range | 300MM*200MM | 350MM*250MM | |
| Stitch Type | Single-needle lockstitch | ||
| Stitch Pitch | 0.05-12.7mm | ||
| Hook Type | Semi-rotating double-hook | ||
| Center Presser Foot Lift | Stepper motor | ||
| Outer Presser Foot Lift | Pneumatic cylinder | ||
| Thread Trimmer | Standard flat-blade thread trimmer | ||
| Thread Wiper | Standard | ||
| Quick Die Change Clamp | Standard | ||
| Power Supply | Standard | ||
| Optional functions | System optional | ||
| 1 | Automatic start clamp | 1 | Button-operated |
| 2 | Sliding clamp | 2 | Horizontal screen |
| 3 | Flip presser foot | 3 | Portrait screen |
| 4 | Machine head start switch | 4 | H-shaped |
| 5 | Thread breakage detection | ||
| 6 | Needle cooling | ||
| 7 | Secondary thread tensioner | ||
| 8 | Cup-shaped auxiliary presser foot | ||
| 9 | Barcode recognition/RFID (available in portrait mode) | ||
| 10 | Electronic thread clamp (available in portrait mode) | ||
| 11 | Network big data function (available in portrait mode) | ||
| Features of this machine | |||
| 1 | Equipped with a standard quick-change die clamp, suitable for combined die processing and sewing. The 3525 size is suitable for processing oversized shoe uppers. |
