The Sanyou Bag Closer Sewing Machine utilizes a direct-drive design, resulting in a low failure rate. Sanyou manufacturer's product adopts direct drive design with low failure rate. Compared with traditional old equipment, it is more durable, has lower failure rate and simpler daily maintenance. If you require more complex pre-sealing processes such as hemming or taping, we have extensive automation modification and customization capabilities and can help you design and integrate a complete automated sealing line.
Through specialized design and optimization, sewing speeds can soar to over 2,000 stitches per minute. This production capacity is quite high. You can seal bags much faster, no matter how many orders you place. In terms of stability, it has a super powerful cloth feeding and presser foot combination, which is a critical design. Especially when sewing thick and slippery materials such as multi-layer woven bags, it can ensure that the bags will not slip, deviate, or skip stitches; after your products are packed, they are absolutely safe on the road and will not crack.
| Standard Specifications | |||
| Model | 3020 | 3525 | |
| Sewing Range | 300MM*200MM | 350MM*250MM | |
| Stitch Type | Single-needle lockstitch | ||
| Stitch Pitch | 0.05-12.7mm | ||
| Hook Type | Semi-rotating double-hook | ||
| Center Presser Foot Lift | Stepper motor | ||
| Outer Presser Foot Lift | Pneumatic cylinder | ||
| Thread Trimmer | Standard flat-blade thread trimmer | ||
| Thread Wiper | Standard | ||
| Quick Die Change Clamp | Standard | ||
| Power Supply | Standard | ||
| Optional Features | |||
| Standard Specifications | System optional | ||
| 1 | Automatic start clamp | 1 | Button-operated |
| 2 | Sliding clamp | 2 | Horizontal screen |
| 3 | Flip presser foot | 3 | Portrait screen |
| 4 | Sewing head start switch | 4 | H-shaped |
| 5 | Thread breakage detection | ||
| 6 | Needle cooling | ||
| 7 | Secondary thread tensioner | ||
| 8 | Bowl-shaped auxiliary presser foot | ||
| 9 | Barcode recognition/RFID (available on portrait models) | ||
| 10 | Electronic thread clamp (available on portrait models) | ||
| 11 | Network big data function (available on portrait models) | ||
